CipherLab RK96 Industrial Terminal (AK96N5F63XSG1)
Regular price
2.142,45 € +VAT
The CipherLab RK96 is CipherLab's latest industrial pistol-grip mobile computer: Wi-Fi 7, Bluetooth 6.0, a Qualcomm octa-core processor, 8 GB / 128 GB memory, Android 15 and a 7000 mAh battery for 14+ hours make it ready for demanding warehouse and logistics operations. This version, AK96N5F63XSG1, offers: Wi-Fi 7 and Bluetooth 6.0, SE5800 extended-range imager, 38-key function numeric keypad, 8 GB RAM / 128 GB Flash, Android 15 with GMS.
📦 What's in the box – AK96N5F63XSG1
- ✅ CipherLab RK96 – mobile computer, Wi-Fi only, SE5800, function numeric (38), 8 GB / 128 GB
- ✅ Trigger handle – fitted to the device
- ✅ Battery – standard 7000 mAh Li-ion, user-replaceable
- ✅ Google Mobile Services (GMS) – licensed and preinstalled – Google Play and Google apps ready to use
- ✅ Quick start guide – drivers, tools and user guides are a free download from CipherLab
- ❌ Charger / power supply – NOT included – needed to charge the battery – see the options below
- ❌ USB-C charging cable – NOT included – USB-C to USB-A, for charging and data – see the options below
- ❌ Charging cradle – NOT included
⚠️ Please note: no charger, charging cable or cradle is included. To charge the RK96, please order separately: the CipherLab BPOWER0000142 USB power adapter with USB-A to USB-C cable – charges the device directly via its USB-C port; or the CipherLab ARK95CCCNU201 charging/communication cradle with its micro-USB cable, powered by a USB power adapter such as the CipherLab BPOWER0000142.
💡 Useful extras: the CipherLab ARK954SBNNE01 4-slot spare battery charger; the CipherLab ARK95MSCNNE01 20-slot battery charger for large fleets; the CipherLab BRK96_PAG0001 protective boot for extra drop protection; the CipherLab XRK9500X01584 hand strap; the CipherLab X970000X01504 holster; a spare USB-C cable (CipherLab WSI0400000001).
Key Features
- Enterprise barcode scanning – the SE5800 extended-range imager reads 1D/2D barcodes quickly and reliably, even when damaged or poorly printed.
- Physical keypad – 38-key function numeric keypad for fast, eyes-free data entry, alongside the touchscreen and programmable scan triggers.
- E-ink display on the back – a 1.3" colour e-paper display shows asset or user information, even when the device is switched off.
- Wi-Fi 7 and Bluetooth 6.0 – tri-band 802.11be with Multi-Link Operation and 320 MHz channels for fast, stable connections in busy warehouses.
- Enterprise Android – Qualcomm QCS6690 octa-core processor, up to 2.9 GHz, 8 GB RAM / 128 GB Flash with microSD slot, Android 15 with Google Mobile Services (GMS) (upgradable to Android 18) and a 16 MP camera with LED flash.
- 4.3" WVGA touchscreen – 480 × 800, readable outdoors, Corning Gorilla Glass; works with gloves, wet fingers and a stylus.
- 7000 mAh battery – 14+ hours of operation per charge; hot-swappable, so you can change it without shutting the device down.
- Rugged and sealed – IP65, multiple 1.8 m drops to concrete (2.4 m with rubber boot) and 1,000 tumbles at 1 m; operating temperature from −20 °C to 50 °C.
- NFC – built-in 13.56 MHz HF RFID/NFC reader (ISO 14443A/B, ISO 15693, FeliCa) for badges, tags and contactless applications.
- Backward compatible – works with RK95 accessories such as the charging cradle and the 4-slot and 20-slot battery chargers.
- Easy deployment and management – CipherLab ReMoCloud, Reader Configuration, AppLock and terminal emulation; supports SOTI MobiControl, Workspace ONE and Ivanti.
Ideal Applications
- Warehouse picking, put-away and replenishment
- Distribution centres and cross-docking
- Goods receipt and shipping with long-range scanning of high racking
- Inventory and cycle counts
- Manufacturing, spare-parts stores and material flow
- Forklift and yard work
All RK96 Versions
The highlighted row is the version you are currently viewing.
| Part Number | Scan Engine | Keypad | |
|---|---|---|---|
| AK96N5F63XSG1 (this version) | SE5800 | Function numeric (38) | Viewing |
| AK96N5F64XSG1 | SE5800 | Function numeric (41) | View product |
| AK96N5F65XSG1 | SE5800 | Alphanumeric (53) | View product |
| AK96NSF63XSG1 | SE4750 SR | Function numeric (38) | View product |
| AK96NMF63XSG1 | SE4750 MR | Function numeric (38) | View product |
Technical Specifications
| Part Number | AK96N5F63XSG1 |
|---|---|
| Model | CipherLab RK96 – Wi-Fi 7 industrial pistol-grip (gun-type) model |
| Operating System | Android 15 with Google Mobile Services (GMS), Android Enterprise Recommended; upgradable to Android 18 (subject to Qualcomm feasibility) |
| Processor | Qualcomm QCS6690 octa-core, up to 2.9 GHz, Edge AI |
| Memory (RAM / Flash) | 8 GB RAM / 128 GB Flash |
| Expansion | microSD slot – SDHC up to 32 GB, SDXC up to 2 TB |
| Display | 4.3" WVGA colour display, Corning Gorilla Glass |
| Touch Panel | Capacitive touch – bare, wet or gloved fingers and stylus |
| E-ink Display | 1.3" e-paper display on the back (144 × 200, red/yellow/black/white) |
| Keypad | 38-key function numeric keypad with LED backlight; enlarged, glove-friendly keys |
| Scan Engine | Zebra SE5800 1D/2D imager (extended range) for codes from close up to far away on high racking |
| Rear Camera | 16 MP PDAF with OIS and LED flash |
| Front Camera | 5 MP |
| Wi-Fi | Wi-Fi 7 – IEEE 802.11 a/b/g/n/ac/ax/be, tri-band 2.4/5/6 GHz, MLO, 320 MHz channels, 2x2 MU-MIMO |
| Bluetooth | Bluetooth 6.0 dual mode, Class II, BLE long range |
| NFC | ISO 14443A/B, ISO 15693, MIFARE, FeliCa; peer-to-peer, card reader and card emulation |
| Mobile Data (WWAN) | Not available – Wi-Fi model |
| Voice & Audio | Speaker with smart amplifier, noise-reducing microphones with echo cancellation, PTT voice, Bluetooth headsets |
| Ports | USB-C (USB 3.1 Gen 1 / USB 2.0 OTG); snap-on USB cable support |
| Sensors | Light, proximity, motion, e-compass, gyroscope |
| Battery | 7000 mAh / 3.635 V (25.45 Wh) Li-ion; hot-swap with temporary session persistence |
| Battery Life | 14+ hours |
| Charging | Via USB-C or the ARK95CCCNU201 charging/communication cradle – not included |
| Form Factor | Industrial gun-type computer with pistol grip |
| Dimensions | 227.6 × 79.8 × 167.5 mm (gun type); terminal 227.6 × 79.8 × 43 mm |
| Weight | 538.2 g (7000 mAh battery, 2D imager) |
| Drop Spec | Multiple 1.8 m drops to concrete (MIL-STD-810G); 2.4 m with rubber boot |
| Tumble Spec | 1000 tumbles at 1 m |
| Sealing | IP65 |
| Operating Temperature | −20 °C to 50 °C |
| Storage Temperature | −30 °C to 70 °C |
| Humidity | 5–95% non-condensing |
| Software & Management | ReMoCloud Express, Pic 'n Fill OCR, Reader Config, terminal emulation, AppLock; SOTI MobiControl, Workspace ONE, Ivanti, StayLinked |
| Warranty | 36 months (3-year CipherLab warranty) |
| In the Box | CipherLab RK96 mobile computer (AK96N5F63XSG1) with pistol grip, 7000 mAh Li-ion battery, Google Mobile Services (GMS) licence preinstalled, quick start guide – charger/power supply, USB-C cable and charging cradle NOT included (order separately) |
The RK96 is the successor to the RK95 and is backward compatible with RK95 accessories. Need a more affordable option? The predecessor, the CipherLab RK95, is also available. Compare all models in our Handheld Terminals collection, or contact our team for volume pricing, staging and MDM set-up.
