The M3 Mobile UL20W is an ultra-rugged Android keypad computer for warehouses, logistics, production and cold-chain work. It combines a 5" Full HD touchscreen, a physical keypad, a 25° angled scan head with a Zebra imager, a hot-swappable 6700 mAh battery and IP67 sealing in a housing that survives 2 m drops. This version, U20W0C-PLCFES-HF, is the Wi-Fi model (with GPS). Configuration: 53-key alphanumeric keypad, the SE4850 long-range imager (reads up to 21.4 m), 2 GB RAM / 16 GB Flash, Android 9 with GMS.
📦 What's in the box – U20W0C-PLCFES-HF
- ✅ M3 Mobile UL20W – mobile computer, black, 5" Full HD, 53 keys, alphanumeric, SE4850, 2 GB / 16 GB
- ✅ Battery – standard 6700 mAh Li-ion, hot-swappable (UL20-BATT-S67)
- ✅ Google Mobile Services (GMS) – licensed and preinstalled – Google Play and Google apps ready to use
- ✅ Quick start guide – drivers, tools and user guides are a free download from M3 Mobile
- ❌ Charger / power supply – NOT included – the UL20W has no charging port of its own – it charges in a charging cradle (see the options below)
- ❌ Charging cradle – NOT included
- ❌ Hand strap – NOT included
⚠️ Please note: no charger, charging cable or cradle is included. To charge the UL20W, please order separately: the M3 UL20-2CRD-CU0 2-slot charging/USB cradle (terminal + spare battery) with the M3 UL20-PWSP-2EU power supply (EU mains cord included); or the M3 UL20-2CRD-EU0 2-slot cradle with Ethernet and USB, also with the M3 UL20-PWSP-2EU power supply.
💡 Useful extras: a spare battery for hot-swapping (M3 UL20-BATT-S67); the M3 UL20-04BC-C00 4-slot spare battery charger (uses the M3 UL20-PWSP-2EU power supply); the M3 UL20-8CRD-C00 or M3 UL20-8CRD-E00 cradles for 4 terminals + 4 spare batteries (with the M3 UL20-PWSP-8EU power supply); the M3 UL20-TRIG-S00 pistol grip for scan-intensive work; a belt holster (M3 UL20-CASE-FHH or M3 UL20-CASE-FSH); the M3 UL20-BOOT-01 protective boot for extra drop protection; hand straps (M3 UL20-STRP-S10, pack of 10); spare screen protectors (M3 UL20-SCPR or M3 UL20-SCPR-G); a vehicle or forklift cradle kit (M3 UL20-CPAK-VCRD, M3 UL20-CPAK-FCRD-UB or M3 UL20-CPAK-FCRD-SQ); a service plan with fast repair and battery replacement (M3 UL20-SPST-XB3-LR or M3 UL20-SPST-XB5-LR).
Key Features
- Ultra-rugged – IP67 dust and water protection, 2 m drops to concrete (3 m with rubber boot) across the operating temperature range and 4,000 tumbles at 1 m.
- 5" Full HD display – 1920 × 1080, readable outdoors, Corning Gorilla Glass; works with gloves, wet fingers or the stylus.
- Fast scanning with an angled scan head – the 25° tilted Zebra SE4850 long-range imager – from arm's length up to 21.4 m lets you aim comfortably while looking at the screen, without bending your wrist.
- Physical keypad for fast data entry – 53-key full alphanumeric layout for extensive text input, plus 6 programmable side keys.
- Wi-Fi model with GPS – dual-band Wi-Fi 5 (802.11ac), Bluetooth 4.1 and GPS/GLONASS/BeiDou/Galileo for indoor sites and yards.
- 6700 mAh battery with hot swap – insulated battery for a full shift, fast charging and battery replacement without switching the device off.
- Enterprise Android – octa-core processor, Android with Google Mobile Services, 16 MP auto-focus camera with flash and NFC (ISO 14443 A/B, ISO 15693).
- Complete accessory system – 2-slot and 8-slot charging/Ethernet cradles, 4-slot battery charger, pistol grip, holsters and vehicle/forklift cradles.
Ideal Applications
- Warehouse picking, put-away, receiving and inventory counts
- Cold stores, frozen food logistics and cold-chain distribution
- Long-range scanning of high-bay racking and pallet labels
- Forklift and vehicle-mounted work
- Manufacturing, work-in-progress tracking and spare-parts stores
- Yards, ports, construction sites and outdoor logistics
All UL20 Versions
The highlighted row is the version you are currently viewing.
| Part Number | Model | Connectivity | Scan Engine | Keypad | Memory | Operating System | |
|---|---|---|---|---|---|---|---|
| U20W0C-P2CFRS-HF | UL20W | Wi-Fi only | SE4750 | 28 keys, numeric | 2 GB / 16 GB | Android 9 | View product |
| U20W0C-P2CFSS-HF | UL20W | Wi-Fi only | SE4750 | 35 keys, function numeric | 2 GB / 16 GB | Android 9 | View product |
| U20W0C-P2CFES-HF | UL20W | Wi-Fi only | SE4750 | 53 keys, alphanumeric | 2 GB / 16 GB | Android 9 | View product |
| U20W0C-PLCFRS-HF | UL20W | Wi-Fi only | SE4850 | 28 keys, numeric | 2 GB / 16 GB | Android 9 | View product |
| U20W0C-PLCFES-HF (this version) | UL20W | Wi-Fi only | SE4850 | 53 keys, alphanumeric | 2 GB / 16 GB | Android 9 | Viewing |
| U20W0C-Q2CFRS-HF | UL20W | Wi-Fi only | SE4750 | 28 keys, numeric | 2 GB / 16 GB | Android 10 | View product |
| U20W0C-Q2CFSS-HF | UL20W | Wi-Fi only | SE4750 | 35 keys, function numeric | 2 GB / 16 GB | Android 10 | View product |
| U20W0C-Q2CFES-HF | UL20W | Wi-Fi only | SE4750 | 53 keys, alphanumeric | 2 GB / 16 GB | Android 10 | View product |
| U20W0C-QICFRS-HF | UL20W | Wi-Fi only | SE5800 | 28 keys, numeric | 2 GB / 16 GB | Android 10 | View product |
| U20X4C-P2CFRS-HF-R | UL20X | 4G LTE + GPS | SE4750 | 28 keys, numeric | 4 GB / 64 GB | Android 9 | View product |
| U20X4C-P2CFSS-HF-R | UL20X | 4G LTE + GPS | SE4750 | 35 keys, function numeric | 4 GB / 64 GB | Android 9 | View product |
| U20X4C-PLCFSS-HF-R | UL20X | 4G LTE + GPS | SE4850 | 35 keys, function numeric | 4 GB / 64 GB | Android 9 | View product |
| U20X4C-Q2CFRS-HF | UL20X | 4G LTE + GPS | SE4750 | 28 keys, numeric | 4 GB / 64 GB | Android 10 | View product |
| U20X4C-Q2CFSS-HF | UL20X | 4G LTE + GPS | SE4750 | 35 keys, function numeric | 4 GB / 64 GB | Android 10 | View product |
| U20X4C-Q2CFES-HF | UL20X | 4G LTE + GPS | SE4750 | 53 keys, alphanumeric | 4 GB / 64 GB | Android 10 | View product |
| U20X4C-QLCFSS-HF | UL20X | 4G LTE + GPS | SE4850 | 35 keys, function numeric | 4 GB / 32 GB | Android 10 | View product |
| U20X4C-QLCFES-HF | UL20X | 4G LTE + GPS | SE4850 | 53 keys, alphanumeric | 4 GB / 32 GB | Android 10 | View product |
| U20X4C-QICFRS-HF | UL20X | 4G LTE + GPS | SE5800 | 28 keys, numeric | 4 GB / 64 GB | Android 10 | View product |
| U20F0C-P2CFRS-HF-R | UL20F (−30 °C) | Wi-Fi only | SE4750 | 28 keys, numeric | 4 GB / 64 GB | Android 9 | View product |
| U20F0C-P2CFSS-HF | UL20F (−30 °C) | Wi-Fi only | SE4750 | 35 keys, function numeric | 4 GB / 32 GB | Android 9 | View product |
| U20F0C-PLCFSS-HF | UL20F (−30 °C) | Wi-Fi only | SE4850 | 35 keys, function numeric | 4 GB / 32 GB | Android 9 | View product |
| U20F0C-PLCFSS-HF-R | UL20F (−30 °C) | Wi-Fi only | SE4850 | 35 keys, function numeric | 4 GB / 64 GB | Android 9 | View product |
| U20F0C-Q2CFRS-HF | UL20F (−30 °C) | Wi-Fi only | SE4750 | 28 keys, numeric | 4 GB / 32 GB | Android 10 | View product |
| U20F0C-Q2CFSS-HF | UL20F (−30 °C) | Wi-Fi only | SE4750 | 35 keys, function numeric | 4 GB / 32 GB | Android 10 | View product |
| U20F0C-Q2CFES-HF | UL20F (−30 °C) | Wi-Fi only | SE4750 | 53 keys, alphanumeric | 4 GB / 32 GB | Android 10 | View product |
| U20F0C-QLCFES-HF | UL20F (−30 °C) | Wi-Fi only | SE4850 | 53 keys, alphanumeric | 4 GB / 32 GB | Android 10 | View product |
| U20F0C-QICFRS-HF | UL20F (−30 °C) | Wi-Fi only | SE5800 | 28 keys, numeric | 4 GB / 64 GB | Android 10 | View product |
| U20F0C-QICFSS-HF | UL20F (−30 °C) | Wi-Fi only | SE5800 | 35 keys, function numeric | 4 GB / 64 GB | Android 10 | View product |
| U20F0C-QICFES-HF | UL20F (−30 °C) | Wi-Fi only | SE5800 | 53 keys, alphanumeric | 4 GB / 64 GB | Android 10 | View product |
| U20F4C-QLCFES-HF | UL20FX (−30 °C) | 4G LTE + GPS | SE4850 | 53 keys, alphanumeric | 4 GB / 64 GB | Android 10 | View product |
| U20F4C-QICFRS-HF | UL20FX (−30 °C) | 4G LTE + GPS | SE5800 | 28 keys, numeric | 4 GB / 64 GB | Android 10 | View product |
| U20F4C-QICFSS-HF | UL20FX (−30 °C) | 4G LTE + GPS | SE5800 | 35 keys, function numeric | 4 GB / 64 GB | Android 10 | View product |
| U20F4C-QICFES-HF | UL20FX (−30 °C) | 4G LTE + GPS | SE5800 | 53 keys, alphanumeric | 4 GB / 64 GB | Android 10 | View product |
Technical Specifications
| Part Number | U20W0C-PLCFES-HF |
|---|---|
| Model | M3 Mobile UL20W – Wi-Fi model of the UL20 ultra-rugged series |
| Operating System | Android 9.0 (Pie) with Google Mobile Services (GMS) |
| Processor | Octa-core, 2.0 GHz |
| Memory (RAM / Flash) | 2 GB RAM / 16 GB Flash |
| Display | 5" Full HD (1920 × 1080), outdoor-viewable, Corning Gorilla Glass |
| Touch Panel | Capacitive multi-touch – finger, glove, wet operation and stylus |
| Keypad | 53-key alphanumeric keypad + 6 programmable side keys |
| Scan Engine | Zebra SE4850 1D/2D long-range imager – reads up to 21.4 m (depending on barcode size); 25° angled scan head |
| Rear Camera | 16 MP auto-focus with LED flash |
| Wi-Fi | Wi-Fi 5 – IEEE 802.11 a/b/g/n/ac/d/e/h/i/k/r/w, dual-band |
| Bluetooth | Bluetooth 4.1 LE, Class II |
| NFC | 13.56 MHz; ISO 14443 A/B, ISO 15693; peer-to-peer, card reader and card emulation |
| Mobile Data (WWAN) | Not available – Wi-Fi only (choose the UL20X for 4G LTE) |
| GPS/GNSS | A-GPS, GLONASS, BeiDou, Galileo |
| Voice & Audio | Speaker, microphone, vibration; Bluetooth headset support |
| Ports | USB 2.0 client (USB-C) and USB 2.0 host (USB-A) via the charging cradle; charging contacts on the device |
| Sensors | Light sensor, proximity sensor, accelerometer, gyroscope, magnetometer (eCompass) |
| Battery | 6700 mAh / 3.6 V Li-ion, insulated (UL20-BATT-S67); hot-swappable |
| Battery Life | Up to 10 hours (M3 user manual) |
| Charging | In a charging cradle (UL20-2CRD-CU0 / UL20-2CRD-EU0 with UL20-PWSP-2EU) or vehicle cradle – not included; fast charging, approx. 4–5 h from empty |
| Form Factor | Ultra-rugged keypad computer with 25° angled scan head |
| Dimensions | 88.7 × 244.75 × 46.19 mm (W × H × D) |
| Weight | 580 g (long-range scanner) |
| Drop Spec | 2 m to concrete (3 m with rubber boot) across the operating temperature range, MIL-STD-810G |
| Tumble Spec | 4,000 tumbles at 1 m (without boot) |
| Sealing | IP67 |
| Operating Temperature | −20 °C to 60 °C |
| Storage Temperature | −30 °C to 80 °C |
| Humidity | 0–95% non-condensing |
| Heater | None |
| Software & Management | M3 Mobile StartUp and ScanEmul; MDM support (e.g. SOTI MobiControl) |
| Colour | Black |
| Warranty | 12 months (M3 Mobile 1-year hardware warranty); 3- and 5-year M3 service packages available |
| In the Box | M3 Mobile UL20W mobile computer (U20W0C-PLCFES-HF), standard 6700 mAh Li-ion battery (UL20-BATT-S67), Google Mobile Services (GMS) licence preinstalled, quick start guide – charging cradle, power supply and hand strap NOT included (order separately) |
The UL20 is M3 Mobile's ultra-rugged keypad computer series with Wi-Fi (UL20W), 4G LTE (UL20X), frozen (UL20F) and frozen 4G (UL20FX) models. Need mobile data on the move? The M3 Mobile UL20X (U20X4C-QLCFES-HF) adds 4G LTE and GPS. Working in cold stores and freezers down to −30 °C? Choose the frozen version with heated display and scan window: M3 Mobile UL20F (U20F0C-QLCFES-HF). Its successor, the M3 Mobile UL30, adds Wi-Fi 6E, Bluetooth 5.3, Android 14 and 8 GB / 128 GB memory. Compare all models in our Handheld Terminals collection, or contact our team for volume pricing, staging and MDM set-up.
