| Part Number |
ET60WW-0S5DPSK0C0-00 |
| Model |
Zebra ET60W (Wi-Fi model) – ET6x series rugged Windows tablet |
| Operating System |
Windows 11 Pro (64-bit) |
| Processor |
Intel Core Ultra 5 125U – 12 cores (2P + 8E + 2LP-E), up to 4.3 GHz, Intel AI Boost NPU |
| Memory (RAM) |
16 GB LPDDR5 |
| Storage |
256 GB M.2 2230 PCIe NVMe SSD, tool-less user-removable |
| Graphics |
Intel Graphics (integrated) |
| Display |
10.1" WUXGA (1920 × 1200), 1,000 nits, optically bonded, 1000:1 contrast |
| Touch Panel |
Capacitive multi-touch with AI-driven touch optimisation – bare or gloved finger, passive stylus (included) or MPP 2.0 active pen; Corning Gorilla Glass |
| Keypad |
On-screen keyboard; optional 2-in-1 keyboard and vehicle keyboards |
| Buttons |
Power, Scan, Up/Down, three programmable keys |
| Scan Engine |
SE55 1D/2D advanced-range imager with IntelliFocus – from near contact up to 12 m; Gorilla Glass exit window |
| Rear Camera |
13 MP autofocus with LED flash |
| Front Camera |
5 MP with privacy shutter + IR camera for Windows Hello face recognition |
| Wi-Fi |
Wi-Fi 7 capable (IEEE 802.11be), Wi-Fi 6E certified; 2x2 MU-MIMO, 320 MHz channels, 4096-QAM, 2.4 / 5 / 6 GHz, up to 5.8 Gbps |
| Bluetooth |
Bluetooth 5.4 Class 1, Bluetooth Low Energy |
| NFC |
Reader/writer: ISO 14443 A/B, MIFARE, FeliCa, ISO 15693, NFC Forum Type 1–4 |
| Mobile Data (WWAN) |
Not available – Wi-Fi only (choose the ET65W for 5G) |
| GPS/GNSS |
Not available (ET65W only) |
| Voice & Audio |
Stereo speakers, two microphones; headsets via USB or Bluetooth |
| Interfaces |
2 × Thunderbolt 4 / USB4 Type-C (45 W USB PD charging), 1 × USB 3.1 Type-A, 1 × USB 2.0 host (back I/O), docking connector, keyboard connector |
| Readers |
No fingerprint reader; NFC; optional smart card / CAC and UHF RFID reader accessories |
| Sensors |
Ambient light sensor, eCompass, 3-axis gyroscope, 3-axis accelerometer |
| Security |
Discrete TPM 2.0, NIST BIOS compliance, FIPS 140-2 validated, Common Criteria certified; Windows Hello face recognition; Absolute Persistence; Kensington lock slots |
| Battery |
36 Wh PowerPrecision+ Li-ion (BTRY-ET6XW-5AH-01), installed; hot-swap for at least 60 s via internal super capacitor |
| Charging |
45 W USB PD 3.0 via either USB-C port (PWR-BGA15V45W-UC2-WW + mains cord) or the vehicle dock – not included; 0–100% in approx. 2.5 h |
| Docking |
Vehicle dock CRD-ET6X-VEHDK-CON-01 / -PTA-01 (heated connectors, battery-free operation) |
| Dimensions |
275 × 199 × 18.3 mm (W × L × H) |
| Weight |
1,248 g (with standard battery) |
| Drop Spec |
1.5 m to concrete (exceeds MIL-STD-810H); 1.8 m to plywood over concrete |
| Sealing |
IP66 (IEC 60529) |
| Operating Temperature |
−29 °C to 63 °C |
| Storage Temperature |
−40 °C to 70 °C |
| Humidity |
5–95% non-condensing |
| Certifications |
MIL-STD-461G / 464D, E-Mark (with keyboard in the vehicle dock), TAA compliant; Class I Division 2 (C1D2) hazardous location |
| Software & Management |
Zebra tools for Windows; Absolute Persistence (activation required) |
| Colour |
Black |
| Warranty |
36 months (Zebra 3-year hardware warranty); Zebra OneCare service plans available |
| In the Box |
Zebra ET60W rugged tablet (ET60WW-0S5DPSK0C0-00), standard 36 Wh battery, installed (BTRY-ET6XW-5AH-01), passive stylus, Windows 11 Pro preinstalled, regulatory guide – 45 W USB-C power supply (PWR-BGA15V45W-UC2-WW) and mains power cord NOT included (order separately) |
