TSC DH240 Desktop Label Printer (DH240-A001-0002)

Regular price 498,77 € +VAT
Power Cord
EUUK
Resolution (dpi)
203300
Wired Interfaces
USBUSB, RS232, Ethernet
Linerless
NoYes
Series
Form Factor
2-inch desktop4-inch desktop
Memory
—RAM: 128 MB, Flash: 128 MBRAM: 16 MB, Flash: 8 MB
Display
3.5" colour touchscreenNone (LED indicators)

Free Shipping over 250 €. Usually delivered within 3–5 working days.

0% VAT for EU/EEA companies (excl. Estonia). Enter a valid VAT number to automatically generate a 0% VAT invoice.

TSC DH240T 4-inch desktop direct thermal label printer, 203 dpi, touch display, black (DH240-A001-0002) – front view
TSC
TSC DH240 Desktop Label Printer (DH240-A001-0002)
Regular price 498,77 € +VAT

The TSC DH240T (DH240-A001-0002) is a 4-inch direct thermal desktop label printer that prints at 203 dpi and up to 203 mm/s (8 ips), with a max. print width of 108 mm – no ribbon needed. A 3.5" colour touch display makes setup and status checks quick. It takes 127 mm (5") label rolls, speaks TSPL-EZD with automatic EPL, ZPL and DPL emulation and connects via USB 2.0, RS-232, 10/100 Ethernet and a USB host port. Supplied with power supply, power cord (EU Schuko plug) and USB cable – ready to print.

📦 What's in the box – DH240-A001-0002

  • ✅ TSC DH240T label printer – 203 dpi, 4" (108 mm), USB 2.0 + RS-232 + Ethernet + USB host
  • ✅ Power supply – external universal power supply, 100–240 V AC → 24 V DC, 90 W
  • ✅ Power cord – EU plug (Schuko)
  • ✅ USB cable – USB 2.0 A-to-B – connect and print straight away
  • ✅ Drivers & software – Windows driver, TSC Console and labeling software – free download from TSC
  • ✅ Setup guide
  • ❌ Labels – NOT included – order labels to suit your application (see compatible labels below)
  • ❌ Ethernet (LAN) cable – NOT included – use any standard RJ45 patch cable

✅ Ready to print: power supply, power cord and USB cable are in the box – you only need direct thermal labels (no ribbon required).

💡 Useful extras: the TSC OP-COM-0002 external roll mount for large rolls on 3" cores; the TSC CUT-TH240-0001 guillotine cutter (full/partial cut) or the TSC PEL-TH240-0001 peel-off module; the TSC WF-TH240-2001 Wi-Fi + Bluetooth 5.0 module for wireless printing; the TSC BP-4000-0002 battery pack to run the printer without a mains socket.

Key Features

  • Direct thermal printing at 203 dpi – up to 203 mm/s (8 ips), max. print width 108 mm; no ribbon to buy or change
  • 3.5" colour touch display (480 × 320) with feed, pause and reprint buttons
  • 127 mm (5") label rolls on 25.4–38.1 mm cores, media 15–120 mm wide (down to 10 mm with the optional adaptor); fanfold, black-mark and notched media
  • TSPL-EZD firmware with automatic EPL, ZPL/ZPL II and DPL language switching – existing label templates print unchanged
  • USB 2.0, RS-232, 10/100 Ethernet and USB host as standard; Wi-Fi 802.11ac + Bluetooth 5.0 or Bluetooth 5.0 modules can be added later
  • 128 MB Flash, 128 MB SDRAM, microSD slot (up to 512 GB) and real-time clock
  • Remote management via embedded web page, virtual control panel, TSC Console and SOTI Connect; HTTPS, SNMPv3 and 802.1X security
  • TPH Care printhead diagnostics and tool-free printhead and platen roller replacement
  • Upgradeable later with peel-off module, guillotine cutter or linerless kits
  • Eco design: 100% recyclable packaging and casing made with 30% recycled plastic; 3-year TSC warranty in EMEA

Ideal Applications

  • Retail – shelf labels, price labels and inventory management
  • Transport and logistics – shipping and receiving labels
  • Healthcare – specimen, pharmacy and patient-tracking labels
  • Food and beverage – product, date and track-and-trace labels
  • Warehousing and manufacturing – picking, bin and work-in-progress labels

All DH Series Versions

The highlighted row is the version you are currently viewing.

Part Number Model Print Width Resolution Display Media Option Interfaces Power Cord
DH220-A001-0002 DH220T 2" (54 mm) 203 dpi 3.5" touch LCD Tear-off USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH220-A001-1002 DH220 2" (54 mm) 203 dpi LED (no display) Tear-off USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH220E-A001-0002 DH220E 2" (54 mm) 203 dpi LED (no display) Tear-off USB only EU (Schuko) View product
DH220E-A001-0003 DH220E 2" (54 mm) 203 dpi LED (no display) Tear-off USB only UK View product
DH320-A001-0002 DH320T 2" (56.9 mm) 300 dpi 3.5" touch LCD Tear-off USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH320-A001-1002 DH320 2" (56.9 mm) 300 dpi LED (no display) Tear-off USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH320E-A001-0002 DH320E 2" (56.9 mm) 300 dpi LED (no display) Tear-off USB only EU (Schuko) View product
DH320E-A001-0003 DH320E 2" (56.9 mm) 300 dpi LED (no display) Tear-off USB only UK View product
DH240-A001-0002 (this version) DH240T 4" (108 mm) 203 dpi 3.5" touch LCD Tear-off USB, RS-232, Ethernet, USB host EU (Schuko) Viewing
DH240-A001-0032 DH240T 4" (108 mm) 203 dpi 3.5" touch LCD Linerless (cutter) USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH240-A001-1002 DH240 4" (108 mm) 203 dpi LED (no display) Tear-off USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH240-A001-1012 DH240 4" (108 mm) 203 dpi LED (no display) Peeler USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH240-A001-1022 DH240 4" (108 mm) 203 dpi LED (no display) Cutter USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH240-A001-1032 DH240 4" (108 mm) 203 dpi LED (no display) Linerless (cutter) USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH240-A001-1042 DH240 4" (108 mm) 203 dpi LED (no display) Linerless (tear-off) USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH340-A001-0002 DH340T 4" (105.7 mm) 300 dpi 3.5" touch LCD Tear-off USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH340-A001-1002 DH340 4" (105.7 mm) 300 dpi LED (no display) Tear-off USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH340-A001-1012 DH340 4" (105.7 mm) 300 dpi LED (no display) Peeler USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH340-A001-1022 DH340 4" (105.7 mm) 300 dpi LED (no display) Cutter USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH340-A001-1032 DH340 4" (105.7 mm) 300 dpi LED (no display) Linerless (cutter) USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH340-A001-1042 DH340 4" (105.7 mm) 300 dpi LED (no display) Linerless (tear-off) USB, RS-232, Ethernet, USB host EU (Schuko) View product

Technical Specifications

Part Number DH240-A001-0002
Model TSC DH240T (DH Series, 4-inch)
Printer Type 4-inch desktop direct thermal label printer
Print Method Direct thermal
Resolution 203 dpi (8 dots/mm)
Print Speed Up to 203 mm/s (8 ips)
Max Print Width 108 mm (4.25")
Max Print Length 25,400 mm (1,000")
Media Width 15–120 mm (0.59"–4.72"); 10 mm with the optional narrow media adaptor
Media Thickness 0.06–0.19 mm (2.36–7.48 mil)
Roll Diameter 127 mm (5") OD
Core Size 25.4–38.1 mm (1"–1.5")
Media Types Continuous, die-cut, black mark, fanfold, notched (outside wound); label length 5 mm – 25,400 mm
Sensors Transmissive gap sensor, reflective black-mark sensor (position adjustable), head-open sensor
Ribbon Not required – direct thermal printing
Interfaces USB 2.0, RS-232 serial, internal Ethernet 10/100 Mbps, USB host; microSD card slot
Wireless None as standard – optional Wi-Fi 802.11a/b/g/n/ac + Bluetooth 5.0 combo module or Bluetooth 5.0 module
Processor 32-bit RISC CPU
Memory 128 MB Flash, 128 MB SDRAM; microSD expansion up to 512 GB (FAT32/exFAT)
Real-Time Clock Standard
Printer Languages TSPL-EZD with automatic EPL, ZPL, ZPL II and DPL language switching
Fonts / Character Sets 8 alphanumeric bitmap fonts; Monotype true-type engine with CG Triumvirate Bold Condensed; ARIALUNI.TTF Unicode font (UTF-8); 0/90/180/270° rotation
Barcodes 1D: Code 39, Code 93, Code 128 (UCC, subsets A/B/C), Codabar, Interleaved 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN/UPC add-on, MSI, Plessey, Postnet, China Post, ITF-14, EAN-14, Code 11, Telepen, Planet, Code 49, Deutsche Post Identcode/Leitcode, LOGMARS; 2D: TLC39, Codablock F, PDF417, MicroPDF417, MaxiCode, DataMatrix, QR Code, Aztec, GS1 DataBar
Display 3.5" colour touch display (480 × 320 px); power, feed, pause and reprint buttons
Media Options Tear-off (standard)
Options Peel-off module, guillotine cutter, linerless tear-off kit, linerless cutter kit, Wi-Fi + Bluetooth 5.0 combo module, Bluetooth 5.0 module, MFi Bluetooth 5.0 (factory option), external label roll mount, KP-200 Plus keyboard, 10 mm narrow media adaptor, BP-4000 battery pack
Management & Security Internal embedded web page, virtual control panel, TSC Console, SOTI Connect (licence); HTTPS, SNMPv3, 802.1X, TCP/IP port 9100 filter; TPH Care printhead diagnostics
Power Supply External universal switching power supply: 100–240 V AC, 2.0 A, 50–60 Hz input; 24 V DC, 3.75 A, 90 W output
Dimensions (W × D × H) 208 × 235 × 170 mm (W × D × H)
Weight 2.1 kg
Color Black
Operating Temperature 0–40 °C, 25–85% RH non-condensing
Storage Temperature −40–60 °C, 10–90% RH non-condensing
Certifications CB, FCC Class B, IC, cTÜVus, NOM, CE Class B, UKCA, EAC, CCC, BIS, RCM, KC, ENERGY STAR 3.0; RoHS, REACH, WEEE
Warranty Printer: 3 years (TSC EMEA, purchases from 1 June 2024); printhead 25 km or 12 months, platen 50 km or 12 months (whichever comes first)
In the Box TSC DH240T printer (203 dpi, 3.5" colour touch LCD, USB 2.0 + RS-232 + Ethernet + USB host), external power supply (24 V DC, 90 W), power cord (EU Schuko plug), USB cable, quick start guide – labels NOT included (direct thermal, no ribbon needed)

Need a different width, resolution, display or media option? All DH Series versions are listed above. Compare other models in our Desktop Label Printers collection or contact our team for volume pricing.
