| Part Number |
SRP-350VK/BEG |
| Model |
BIXOLON SRP-350V |
| Printer Type |
POS thermal receipt printer (single-station) |
| Print Method |
Direct thermal line printing; 2-colour printing supported |
| Resolution |
180 × 180 dpi (7 dots/mm) |
| Print Speed |
Up to 300 mm/s |
| Paper Width |
80 mm (optional 58 mm); print width up to 72 mm |
| Characters per Line |
Font A: 42, Font B/C: 56 (KOR/CHN/JPN: 21) |
| Roll Diameter |
Max. 83 mm |
| Paper Thickness |
0.05–0.08 mm |
| Auto-cutter |
Auto-cutter; life approx. 2 million cuts |
| Interfaces |
USB 2.0 Full Speed (Type-B) |
| Drawer Kick-out |
Yes – drawer kick-out port (24 V); 2 drawers via Y-type adapter |
| Emulation / Command Set |
BXL/POS |
| Fonts / Character Sets |
Font A 12 × 24, Font B 9 × 17, Font C 9 × 24; KOR/CHN/JPN 24 × 24; 95 alphanumeric, 32 international character sets, 128 × 35 pages extended graphics; user-defined fonts and logos |
| Barcodes |
1D: Codabar, Code 39, Code 93, Code 128, EAN-8, EAN-13, ITF, UPC-A, UPC-E; 2D: Data Matrix, PDF417, QR Code |
| Drivers & Software |
Windows driver, OPOS/JPOS, Linux/Mac CUPS, Virtual COM (USB) driver, Network Auto Installer; Android/iOS/Windows/Linux/Xamarin SDK, Web Print SDK, Cordova plugin, mPrint app (Android, iOS) |
| Memory |
64 Mb SDRAM, 64 Mb Flash; NV image memory 256 KB |
| Data Buffer |
Receive buffer 4 KB; user-defined buffer 12 KB |
| Sensors |
Paper end, paper near-end, cover open, Visibility Intelligence sensor |
| Power Supply |
External power adapter (included), 24 V DC; AC 100–240 V, 50/60 Hz; optional built-in power supply (RSB-350V/RSB-350VK) |
| Dimensions (W × D × H) |
145 × 204 × 146 mm |
| Weight |
1.6 kg |
| Color |
Black |
| Options |
Built-in power supply (RSB-350V/RSB-350VK), vertical stand (RVS-350V/RVS-350VK), splash-proof cover (RSC-350plus), cable cover, external buzzer (RBC-100), B-Melodist (RMB-100G), serial cables (9-9 / 9-25 pin) |
| Operating Temperature |
0 °C to 40 °C |
| Storage Temperature |
−20 °C to 60 °C |
| Humidity |
10–80% RH (operation); 10–90% RH (storage) |
| Print Head Life |
150 km |
| Certifications |
ENERGY STAR certified |
| Warranty |
24 months |
| In the Box |
BIXOLON SRP-350V printer (USB, black), external power adapter (24 V DC) with EU (Schuko) power cord, USB A-B cable (1.8 m), starter paper roll, quick start guide |
