M3 Mobile SM20 x Terminal (SM2X4R-R2CHSS-HF)

The M3 Mobile SM20 X is a rugged full-touch Android mobile computer in a slim smartphone format – built for retail, warehouse, logistics, delivery and field-service staff who scan all day. It combines a 5" HD Gorilla Glass display, a 2.0 GHz Qualcomm Snapdragon 662 octa-core processor, 4 GB RAM / 64 GB flash, 4G LTE, Wi-Fi 5, Bluetooth 5.1, NFC, a hot-swappable battery and IP65 sealing. This version, SM2X4R-R2CHSS-HF, is the standard model with 4G LTE and GPS for −20 °C to 60 °C. Configuration: the SE4710 2D imager, 4 GB RAM / 64 GB flash, Android 11 with GMS, standard 4100 mAh battery.

Key Features

• Rugged yet slim – only 22 mm thin and 266 g light, IP65 dust and water protection, 1.2 m drops to concrete (1.8 m with protective boot) and 500 tumbles at 1 m with boot.
• 4G LTE and GPS – mini SIM + eSIM, LTE mobile data with VoLTE plus GPS, GLONASS, Galileo and BeiDou; also Wi-Fi 5 and Bluetooth 5.1.
• SE4710 2D imager – reliable 1D/2D reading of everyday barcodes, also from smartphone screens.
• 5" HD display – Corning Gorilla Glass touchscreen, readable outdoors and usable with gloves; 2 side scan keys plus Home, Back, Menu and Enter keys.
• 4100 mAh battery with hot swap – change the battery without switching off; an extended 6150 mAh battery is available for longer shifts.
• Performance and long Android support – Qualcomm Snapdragon 662, octa-core 2.0 GHz, 4 GB RAM / 64 GB flash (microSD up to 512 GB), Android 11 with GMS and planned upgrades up to Android 13, 16 MP auto-focus rear camera and 5 MP front camera.
• Uses the SM15 accessory range – SM15 charging and Ethernet cradles, USB snap-on chargers, pistol grips, UHF RFID snap-on, wearable mounts and vehicle cradles fit the SM20, so existing SM15 installations can be upgraded easily.
• M3 SPEEDPACK – the StartUp tool configures hundreds of devices at once by scanning a few barcodes; MDM support (e.g. SOTI).

Ideal Applications

• Warehouse picking, receiving, put-away and inventory
• Cold-chain logistics, cold stores and deep-freeze warehouses (F model)
• Retail stock and price checks, click and collect and mobile POS
• Parcel, courier and last-mile delivery with proof of delivery
• Field service, maintenance and asset tracking
• Transport, logistics and yard management
• Manufacturing and spare-parts stores

All SM20 Versions

The highlighted row is the version you are currently viewing.

Technical Specifications

The SM20 series comes as the standard SM20 (−20 °C to 60 °C) and the SM20 F frozen model (−30 °C to 60 °C), each with 4G LTE and a choice of scan engines and batteries. For cold stores and freezers, choose the F model M3 Mobile SM20 F (SM2F4R-R2CHSS-HF). Prefer a different scan engine? The M3 Mobile SM20 X (SM2X4R-RFCHSS-HF) comes with the SE5500 Smart Focus imager for codes near and far. Its predecessor is the M3 Mobile SM15; M3 Mobile's current flagship full-touch model is the M3 Mobile SM30. Compare all models in our Handheld Terminals collection, or contact our team for volume pricing, staging and MDM set-up.
