TSC DH340HC Desktop Label Printer (DH340HC-A001-0002)

Regular price 740,38 € +VAT
Resolution (dpi)
203300
Form Factor
2-inch desktop4-inch desktop

Free Shipping over 250 €. Usually delivered within 3–5 working days.

0% VAT for EU/EEA companies (excl. Estonia). Enter a valid VAT number to automatically generate a 0% VAT invoice.

TSC DH340THC 4-inch healthcare desktop direct thermal label printer, 300 dpi, touch display, white (DH340HC-A001-0002) – front view
TSC
TSC DH340HC Desktop Label Printer (DH340HC-A001-0002)
Regular price 740,38 € +VAT

The TSC DH340THC (DH340HC-A001-0002) is a 4-inch healthcare desktop label printer for direct thermal printing at 300 dpi and up to 152 mm/s (6 ips), with a max. print width of 105.7 mm – no ribbon needed. Its white, antibacterial and disinfectant-ready housing with sealed buttons and an IEC 60601-1 medical-grade power supply make it a natural fit for hospitals, laboratories and pharmacies. It takes 127 mm (5") label rolls, a 3.5" colour touch display guides the user, and the printer connects via USB 2.0, RS-232, 10/100 Ethernet and a USB host port. Supplied with power supply, power cord (EU Schuko plug) and USB cable – ready to print.

📦 What's in the box – DH340HC-A001-0002

  • ✅ TSC DH340THC label printer – 300 dpi, 4" (105.7 mm), USB 2.0 + RS-232 + Ethernet + USB host
  • ✅ Power supply – IEC 60601-1 medical-grade power supply, 100–240 V AC → 24 V DC, 90 W
  • ✅ Power cord – EU plug (Schuko)
  • ✅ USB cable – USB 2.0 A-to-B – connect and print straight away
  • ✅ Drivers & software – Windows driver, TSC Console and labeling software – free download from TSC
  • ✅ Setup guide
  • ❌ Labels – NOT included – order labels to suit your application (see compatible labels below)
  • ❌ Ethernet (LAN) cable – NOT included – use any standard RJ45 patch cable

✅ Ready to print: power supply, power cord and USB cable are in the box – you only need direct thermal labels (no ribbon required).

💡 Useful extras: the TSC OP-COM-0002 external roll mount for large rolls on 3" cores; the TSC CUT-TH240-0001 guillotine cutter (full/partial cut) or the TSC PEL-TH240-0001 peel-off module.

Key Features

  • Direct thermal printing at 300 dpi – up to 152 mm/s (6 ips), max. print width 105.7 mm; no ribbon to buy or change
  • Healthcare design: white antibacterial, disinfectant-ready enclosure with an easy-to-clean surface and sealed buttons
  • IEC 60601-1 certified medical-grade power supply for safe use in clinical environments
  • 3.5" colour touch display (480 × 320) with feed, pause and reprint buttons
  • 127 mm (5") label rolls on 25.4–38.1 mm cores, media 15–120 mm wide (down to 10 mm with the optional adaptor); fanfold, black-mark and notched media
  • TSPL-EZD firmware with automatic EPL, ZPL/ZPL II and DPL language switching – existing label templates print unchanged
  • USB 2.0, RS-232, 10/100 Ethernet and USB host as standard; Wi-Fi + Bluetooth 5.0 or Bluetooth 5.0 modules can be added later
  • 128 MB Flash, 128 MB SDRAM, microSD slot (up to 512 GB) and real-time clock
  • Remote management via embedded web page, TSC Console and SOTI Connect; HTTPS, SNMPv3 and 802.1X security
  • Upgradeable later with peel-off module, guillotine cutter or linerless kits; 3-year TSC warranty in EMEA

Ideal Applications

  • Laboratories – specimen and sample tube labels
  • Pharmacies – medication and prescription labels
  • Hospitals – patient tracking, admission and chart labels
  • Clinics, care homes and veterinary practices – sample, medication and file labels
  • Blood banks and sterile services – traceability labels

All DH Series for Healthcare Versions

The highlighted row is the version you are currently viewing.

Part Number Model Print Width Resolution
DH220HC-A001-0002 DH220THC 2" (54 mm) 203 dpi View product
DH320HC-A001-0002 DH320THC 2" (56.9 mm) 300 dpi View product
DH240HC-A001-0002 DH240THC 4" (108 mm) 203 dpi View product
DH340HC-A001-0002 (this version) DH340THC 4" (105.7 mm) 300 dpi Viewing

Technical Specifications

Part Number DH340HC-A001-0002
Model TSC DH340THC (DH Series for Healthcare, 4-inch)
Printer Type 4-inch desktop direct thermal label printer for healthcare
Print Method Direct thermal
Resolution 300 dpi (12 dots/mm)
Print Speed Up to 152 mm/s (6 ips)
Max Print Width 105.7 mm (4.16")
Max Print Length 11,430 mm (450")
Media Width 15–120 mm (0.59"–4.72"); 10 mm with the optional narrow media adaptor
Media Thickness 0.06–0.19 mm (2.36–7.48 mil)
Roll Diameter 127 mm (5") OD
Core Size 25.4–38.1 mm (1"–1.5")
Media Types Continuous, die-cut, black mark, fanfold, notched (outside wound); label length 5 mm – 11,430 mm
Sensors Transmissive gap sensor, reflective black-mark sensor (position adjustable), head-open sensor
Ribbon Not required – direct thermal printing
Interfaces USB 2.0, RS-232 serial, internal Ethernet 10/100 Mbps, USB host; microSD card slot
Wireless None as standard – optional Wi-Fi 802.11a/b/g/n/ac + Bluetooth 5.0 combo module or Bluetooth 5.0 module
Processor 32-bit RISC CPU
Memory 128 MB Flash, 128 MB SDRAM; microSD expansion up to 512 GB (FAT32/exFAT)
Real-Time Clock Standard
Printer Languages TSPL-EZD with automatic EPL, ZPL, ZPL II and DPL language switching
Fonts / Character Sets 8 alphanumeric bitmap fonts; Monotype true-type engine with CG Triumvirate Bold Condensed; ARIALUNI.TTF Unicode font (UTF-8); 0/90/180/270° rotation
Barcodes 1D: Code 39, Code 93, Code 128 (UCC, subsets A/B/C), Codabar, Interleaved 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN/UPC add-on, MSI, Plessey, Postnet, China Post, ITF-14, EAN-14, Code 11, Telepen, Planet, Code 49, Deutsche Post Identcode/Leitcode, LOGMARS; 2D: TLC39, Codablock F, PDF417, MicroPDF417, MaxiCode, DataMatrix, QR Code, Aztec, GS1 DataBar
Display 3.5" colour touch display (480 × 320 px); power, feed, pause and reprint buttons
Media Options Tear-off (standard)
Options Peel-off module, guillotine cutter, linerless tear-off kit, linerless cutter kit, Wi-Fi + Bluetooth 5.0 combo module, Bluetooth 5.0 module, MFi Bluetooth 5.0 (factory option), external label roll mount, KP-200 Plus keyboard, 10 mm narrow media adaptor
Management & Security Internal embedded web page, virtual control panel, TSC Console, SOTI Connect (licence); HTTPS, SNMPv3, 802.1X, TCP/IP port 9100 filter; TPH Care printhead diagnostics
Enclosure Double-walled clamshell; disinfectant-ready, antibacterial plastic with easy-to-clean surface and sealed buttons
Power Supply External IEC 60601-1 certified power supply: 100–240 V AC, 2.0 A, 50–60 Hz input; 24 V DC, 3.75 A, 90 W output
Dimensions (W × D × H) 208 × 235 × 170 mm (W × D × H)
Weight 2.1 kg
Color White
Operating Temperature 0–40 °C, 25–85% RH non-condensing
Storage Temperature −40–60 °C, 10–90% RH non-condensing
Certifications CB, FCC Class B, IC, cTÜVus, CE Class B, UKCA, EAC, CCC, BIS, RCM, BSMI, KC, ENERGY STAR 3.0; RoHS, REACH, WEEE
Warranty Printer: 3 years (TSC EMEA, purchases from 1 June 2024); printhead 25 km or 12 months, platen 50 km or 12 months (whichever comes first)
In the Box TSC DH340THC printer (300 dpi, 3.5" colour touch LCD, USB 2.0 + RS-232 + Ethernet + USB host), IEC 60601-1 medical-grade external power supply (24 V DC, 90 W), power cord (EU Schuko plug), USB cable, quick start guide – labels NOT included (direct thermal, no ribbon needed)

Need a different width or resolution? All DH Series healthcare versions are listed above. Compare other models in our Desktop Label Printers collection or contact our team for volume pricing.
