The TSC TX210 (TX210-A001-1303) is a 4-inch performance desktop label printer for thermal-transfer and direct-thermal printing at 203 dpi and up to 203 mm/s (8 ips), with a max. print width of 108 mm. This LED version keeps operation simple with eight large status icons and a single feed/pause button. Its rugged double-walled housing takes 127 mm label rolls and large 300 m ribbons, speaks TSPL-EZD with EPL, ZPL and DPL compatibility and connects via USB 2.0, RS-232, 10/100 Ethernet and USB host. Up to 8 ips makes it a fast choice for high-volume shipping labels. Supplied with power supply, UK power cord and USB cable – ready to print.
📦 What's in the box – TX210-A001-1303
- ✅ TSC TX210 label printer – 203 dpi, 4" (108 mm), LED icon panel, USB 2.0 + RS-232 + Ethernet + USB host
- ✅ Power supply – external universal power supply, 100–240 V AC → 24 V DC, 90 W
- ✅ Power cord – UK plug (type G)
- ✅ USB cable – USB 2.0 A-to-B – connect and print straight away
- ✅ Windows labeling software – TSC labeling software and driver on CD (also a free download from TSC)
- ✅ Setup guide
- ❌ Thermal-transfer ribbon – NOT included – needed for thermal-transfer printing only – direct-thermal labels print without a ribbon
- ❌ Labels – NOT included – order labels to suit your application (see compatible labels below)
- ❌ Ethernet (LAN) cable – NOT included – use any standard RJ45 patch cable
✅ Ready to print: power supply, power cord and USB cable are in the box – you only need labels (and a ribbon for thermal-transfer printing).
💡 Useful extras: ribbons with the ink on the OUTSIDE, e.g. the TSC 8050-SWX (P159049-001) (110 mm × 300 m on a 1" core); the TSC CUT-TX210-0001 guillotine cutter (full cut) or the TSC PEL-TX210-0001 peel-off module; the TSC OP-COM-0002 external roll mount for large rolls on 3" cores; the TSC WF-TX210-2002 Wi-Fi slot-in upgrade kit for wireless network printing.
Key Features
- Thermal transfer and direct thermal at 203 dpi – up to 203 mm/s (8 ips), max. print width 108 mm, max. print length 25,400 mm
- LED panel with eight large status icons and one feed/pause button – simple operation without menus
- Large 300 m ribbons on a 1" core (ink outside), 40–110 mm wide – fewer ribbon changes and a lower cost per label
- Self-centring label holder for 127 mm (5") rolls on 1" or 1.5" cores; media 19–112 mm wide, 0.055–0.254 mm thick; fanfold, black-mark and notched media
- TSPL-EZD firmware compatible with EPL, ZPL, ZPL II and DPL – existing label formats print unchanged
- USB 2.0, RS-232, 10/100 Ethernet and USB host as standard; a Wi-Fi 802.11ac + Bluetooth 4.2 combo module can be added later
- 128 MB Flash, 128 MB SDRAM and microSD slot (up to 32 GB)
- Rugged double-walled housing, ADF hinge and industrial-grade hybrid motor for a stable media path and accurate printing
- Heat-line adjustment for different media, TPH Care printhead diagnostics and an enhanced ribbon stop that prevents ribbon rewind when the cover is opened
- Remote printer management with TSC Console and SOTI Connect over Ethernet or Wi-Fi
- Optional peel-off module, guillotine cutter, external roll mount and KP-200 Plus keyboard; 3-year TSC warranty in EMEA
Ideal Applications
- Manufacturing – product marking, compliance labels and inventory control
- Transport and logistics – shipping and receiving labels
- Healthcare – specimen, pharmacy and patient-tracking labels
- Retail and warehousing – shelf, price and asset labels
- High-volume shipping labels and safety signage
All TX210 Series Versions
The highlighted row is the version you are currently viewing.
| Part Number | Model | Resolution | Display | Power Cord | |
|---|---|---|---|---|---|
| TX210-A001-1202 | TX210 | 203 dpi | 3.5" colour LCD | EU (Schuko) | View product |
| TX210-A001-1203 | TX210 | 203 dpi | 3.5" colour LCD | UK | View product |
| TX210-A001-1302 | TX210 | 203 dpi | LED icon panel | EU (Schuko) | View product |
| TX210-A001-1303 (this version) | TX210 | 203 dpi | LED icon panel | UK | Viewing |
| TX310-A001-1202 | TX310 | 300 dpi | 3.5" colour LCD | EU (Schuko) | View product |
| TX310-A001-1203 | TX310 | 300 dpi | 3.5" colour LCD | UK | View product |
| TX310-A001-1302 | TX310 | 300 dpi | LED icon panel | EU (Schuko) | View product |
| TX310-A001-1303 | TX310 | 300 dpi | LED icon panel | UK | View product |
| TX610-A001-1202 | TX610 | 600 dpi | 3.5" colour LCD | EU (Schuko) | View product |
Technical Specifications
| Part Number | TX210-A001-1303 |
|---|---|
| Model | TSC TX210 (TX210 Series, 4-inch) |
| Printer Type | 4-inch desktop thermal transfer label printer |
| Print Method | Thermal transfer and direct thermal |
| Resolution | 203 dpi (8 dots/mm) |
| Print Speed | Up to 203 mm/s (8 ips) |
| Max Print Width | 108 mm (4.25") |
| Max Print Length | 25,400 mm (1,000") |
| Media Width | 19–112 mm (0.75"–4.4") |
| Media Thickness | 0.055–0.254 mm (2.17–10 mil) |
| Roll Diameter | 127 mm (5") OD |
| Core Size | 25.4–38.1 mm (1"–1.5") |
| Media Types | Continuous, die-cut, black mark, fanfold, notched (outside wound); label length 3 mm – 25,400 mm |
| Sensors | Transmissive gap sensor, reflective black-mark sensor (position adjustable), ribbon encoder sensor, head-open sensor; ribbon-end sensor as factory option |
| Ribbon | 300 m on 1" (25.4 mm) core, max. OD 67 mm; width 40–110 mm; ink coated OUTSIDE |
| Interfaces | USB 2.0, RS-232 serial, internal Ethernet 10/100 Mbps, USB host; microSD card slot; Centronics parallel (factory option) |
| Wireless | None as standard – optional Wi-Fi 802.11a/b/g/n/ac + Bluetooth 4.2 combo module (dealer option); MFi Bluetooth 5.0 (factory option) |
| Processor | 32-bit RISC CPU |
| Memory | 128 MB Flash, 128 MB SDRAM; microSD expansion up to 32 GB |
| Real-Time Clock | Optional (dealer option) |
| Printer Languages | TSPL-EZD (compatible with EPL, ZPL, ZPL II and DPL) |
| Fonts / Character Sets | 8 alphanumeric bitmap fonts; Monotype true-type engine with CG Triumvirate Bold Condensed scalable font; 0/90/180/270° rotation |
| Barcodes | 1D: Code 39, Code 93, Code 128 (UCC, subsets A/B/C), Codabar, Interleaved 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN/UPC add-on, MSI, Plessey, Postnet, China Post, ITF-14, EAN-14, Code 11, Telepen, Planet, Code 49, Deutsche Post Identcode/Leitcode, LOGMARS; 2D: TLC39, Codablock F, PDF417, MicroPDF417, MaxiCode, DataMatrix, QR Code, Aztec, GS1 DataBar |
| Display | No display – LED panel with 8 large status icons; feed/pause button and power switch |
| Media Options | Tear-off (standard); peel-off module and guillotine cutter (full cut) optional |
| Options | Peel-off module, guillotine cutter (full cut), Wi-Fi + Bluetooth 4.2 combo module, external label roll mount, KP-200 Plus keyboard, real-time clock |
| Management & Security | TSC Console, SOTI Connect (licence) via Ethernet or Wi-Fi; TPH Care printhead diagnostics |
| Enclosure | Clamshell with double-walled plastic, ADF hinge |
| Power Supply | External universal switching power supply: 100–240 V AC, 2.5 A, 50–60 Hz input; 24 V DC, 3.75 A, 90 W output |
| Dimensions (W × D × H) | 226 × 332 × 198 mm (W × D × H) |
| Weight | 3.75 kg |
| Color | Black |
| Operating Temperature | 5–40 °C, 25–85% RH non-condensing |
| Storage Temperature | −40–60 °C, 10–90% RH non-condensing |
| Certifications | FCC Class B, CE Class B, RCM, UL, cUL, TÜV/Safety, CCC, BIS, EAC, ENERGY STAR; RoHS, WEEE |
| Warranty | Printer: 3 years (TSC EMEA, purchases from 1 June 2024); printhead 25 km or 12 months, platen 50 km or 12 months (whichever comes first) |
| In the Box | TSC TX210 printer (203 dpi, LED icon panel, USB 2.0 + RS-232 + Ethernet + USB host), external power supply (24 V DC, 90 W), power cord (UK plug), USB cable, Windows labeling software CD, quick start guide – ribbon and labels NOT included |
Need a different resolution, display or plug? All TX210 Series versions are listed above. Compare other models in our Desktop Label Printers collection or contact our team for volume pricing.
