| Part Number |
ZQ21-A0E12KE-00 |
| Model |
Zebra ZQ210 |
| Printer Type |
Mobile receipt and label printer, 2-inch |
| Print Method |
Direct thermal |
| Resolution |
203 dpi (8 dots/mm) |
| Print Speed |
Up to 50 mm/s (2 in/s) on linerless media |
| Max Print Width |
48 mm (1.89 in) |
| Media Width |
58 mm; 50.8, 40 or 30 mm with the optional media spacers |
| Roll Diameter |
Max. 40 mm (1.57 in) outer diameter |
| Core Size |
12.7 mm (0.5 in) |
| Paper Thickness |
0.058–0.1575 mm |
| Media Types |
Linerless labels (linerless platen), continuous and black-mark receipts |
| Sensors |
Black mark, gap, media out |
| Interfaces |
USB 2.0 Type-C |
| Wireless |
Bluetooth 2.1 + EDR / 4.1 Low Energy dual mode, MFi certified |
| NFC |
Passive NFC tag – tap-to-pair |
| Printer Languages |
CPCL and ESC/POS |
| Fonts / Character Sets |
CPCL: English / Latin9, Cyrillic; ESC/POS: Font A 12×24, Font B 9×17, Font C 9×24 |
| Barcodes |
1D: Code 39, Code 93, GS1-128, Code 128, Codabar, Interleaved 2 of 5, UPC-A, UPC-E, EAN-8, EAN-13 (2/5-digit add-on and composite); 2D: PDF417, MicroPDF417, MaxiCode, QR Code, GS1 DataBar, Aztec, MSI / Plessey |
| Memory |
16 MB SDRAM, 16 MB Flash |
| Display |
OLED screen with control buttons |
| Drivers & Software |
Zebra Printer Setup Utility (Windows, iOS, Android), OPOS driver, Zebra NetBridge, ZebraDesigner driver, ZebraLink / Multiplatform SDK |
| Mobile Printing |
Android, iOS (MFi), Windows |
| Battery |
1500 mAh, 7.4 V Li-ion, user replaceable (included); spare battery BTRY-MPV-15MA1-01 |
| Printing per Charge |
Min. 500 labels of 8.5 in (216 mm) at 13% density |
| Charging |
USB charging via USB-C (approx. 3.5 h) from a PC, USB AC adapter or vehicle USB / lighter adapter; 5-slot charging cradle CRD-MPV-5SC2EU1-01 / UK1-01 (optional) |
| Environmental Sealing |
IP43 (IP54 with soft case) |
| Drop Specification |
1.5 m (5 ft) to concrete |
| Dimensions (W × D × H) |
118 × 85.5 × 44.5 mm |
| Weight |
265 g (with battery) |
| Color |
Black |
| Operating Temperature |
−10 °C to 50 °C (charging 0–40 °C) |
| Storage Temperature |
−20 °C to 60 °C |
| Certifications |
EN60950, EN62368; EN55032, EN55035, ETSI EN 301 489-1 / -17 |
| Warranty |
12 months |
| In the Box |
Zebra ZQ210 printer (Bluetooth 4.1 MFi + USB-C + NFC, linerless platen, black), 1500 mAh 7.4 V Li-ion battery, USB-A to USB-C cable (charging and data), belt clip – USB power adapter, media and soft case NOT included (order separately) |
