TSC DH220LHC Desktop Label Printer (DH220LHC-A001-1212)

Regular price 561,02 € +VAT
Wireless
Linerless
NoYes
Series
CutterPeeler / dispenserTear-off
Display
3.5" colour touchscreenNone (LED indicators)

Free Shipping over 250 €. Usually delivered within 3–5 working days.

0% VAT for EU/EEA companies (excl. Estonia). Enter a valid VAT number to automatically generate a 0% VAT invoice.

TSC TH/DH220THC Series (DH220LHC-A001-1212)
TSC
TSC DH220LHC Desktop Label Printer (DH220LHC-A001-1212)
Regular price 561,02 € +VAT

The TSC DH220LHC (DH220LHC-A001-1212) is a 2-inch healthcare desktop label printer for direct-thermal printing at 203 dpi and up to 203 mm/s (8 ips), with a max. print width of 54 mm. Its white, antibacterial and disinfectant-ready housing with sealed buttons and an IEC 60601-1 medical-grade power supply suit hospitals, laboratories and pharmacies. This LED version keeps operation simple with status icons and feed, pause and reprint buttons. A factory-fitted peel-off module presents each label ready to apply. It holds large label rolls up to 165 mm (6.5") OD, handles labels, tags and patient wristbands 10–60 mm wide, speaks TSPL-EZD with automatic EPL, ZPL and DPL emulation and connects via USB 2.0, RS-232, 10/100 Ethernet and USB host, plus factory-installed MFi Bluetooth for iOS and Android. Supplied with power supply, EU power cord and USB cable – ready to print.

📦 What's in the box – DH220LHC-A001-1212

  • ✅ TSC DH220LHC label printer – 203 dpi, 2" (54 mm), USB 2.0 + RS-232 + Ethernet + USB host, MFi Bluetooth
  • ✅ Peel-off module (factory-fitted) – dispenses each label from the liner, ready to apply
  • ✅ Power supply – IEC 60601-1 medical-grade power supply, 100–240 V AC → 24 V DC, 60 W
  • ✅ Power cord – EU plug (Schuko)
  • ✅ USB cable – USB 2.0 A-to-B – connect and print straight away
  • ✅ Drivers & software – Windows driver, TSC Console and labeling software – free download from TSC
  • ✅ Setup guide
  • ❌ Labels / wristbands – NOT included – order labels to suit your application (see compatible labels below)
  • ❌ Ethernet (LAN) cable – NOT included – use any standard RJ45 patch cable

✅ Ready to print: power supply, power cord and USB cable are in the box – you only need labels or wristbands (direct thermal – no ribbon required).

💡 Useful extras: the TSC CUT-DH220-0001 linerless cutter kit or the TSC TEAR-DH220-0001 linerless tear-off kit to print liner-free labels; the TSC OP-COM-0002 external roll mount for large rolls on 3" cores.

Key Features

  • Direct thermal at 203 dpi – up to 203 mm/s (8 ips), max. print width 54 mm, labels up to 25.4 m long
  • Healthcare design: white antibacterial, disinfectant-ready enclosure with an easy-to-clean surface and sealed buttons
  • IEC 60601-1 certified medical-grade power supply for safe use in clinical environments
  • Large 165 mm (6.5") label rolls on 25.4–38.1 mm cores, media 10–60 mm wide: die-cut, continuous, black-mark, fanfold and notched labels, tags and patient wristbands
  • LED status and icon indicators with feed, pause and reprint buttons – nothing to configure
  • Factory-fitted peel-off module for print-and-apply labelling at the bedside or bench
  • TSPL-EZD firmware with automatic EPL, ZPL/ZPL II and DPL language switching – existing label templates print unchanged
  • USB 2.0, RS-232, 10/100 Ethernet and USB host plus factory-installed MFi Bluetooth for printing from iOS and Android devices
  • 256 MB SDRAM, 512 MB Flash, microSD slot (up to 512 GB), real-time clock and buzzer
  • Remote management via embedded web page, TSC Console and SOTI Connect; HTTPS, SNMPv3 and 802.1X security
  • 3-year TSC printer warranty in EMEA

Ideal Applications

  • Hospitals – patient ID wristbands, admission and chart labels
  • Laboratories – specimen and sample tube labels
  • Pharmacies – medication and prescription labels
  • Blood banks and sterile services – traceability labels
  • Clinics, care homes and veterinary practices – sample, medication and file labels

All DH220LHC Versions

The highlighted row is the version you are currently viewing.

Part Number Display Media Option Linerless Wireless
DH220LHC-A001-0002 3.5" touch LCD Tear-off No — View product
DH220LHC-A001-0012 3.5" touch LCD Peeler No — View product
DH220LHC-A001-0022 3.5" touch LCD Cutter No — View product
DH220LHC-A001-0032 3.5" touch LCD Cutter Yes — View product
DH220LHC-A001-0042 3.5" touch LCD Tear-off Yes — View product
DH220LHC-A001-0102 3.5" touch LCD Tear-off No Wi-Fi + Bluetooth View product
DH220LHC-A001-0112 3.5" touch LCD Peeler No Wi-Fi + Bluetooth View product
DH220LHC-A001-0122 3.5" touch LCD Cutter No Wi-Fi + Bluetooth View product
DH220LHC-A001-0132 3.5" touch LCD Cutter Yes Wi-Fi + Bluetooth View product
DH220LHC-A001-0142 3.5" touch LCD Tear-off Yes Wi-Fi + Bluetooth View product
DH220LHC-A001-0202 3.5" touch LCD Tear-off No Bluetooth (MFi) View product
DH220LHC-A001-0212 3.5" touch LCD Peeler No Bluetooth (MFi) View product
DH220LHC-A001-0222 3.5" touch LCD Cutter No Bluetooth (MFi) View product
DH220LHC-A001-0232 3.5" touch LCD Cutter Yes Bluetooth (MFi) View product
DH220LHC-A001-0242 3.5" touch LCD Tear-off Yes Bluetooth (MFi) View product
DH220LHC-A001-1002 LED (no display) Tear-off No — View product
DH220LHC-A001-1012 LED (no display) Peeler No — View product
DH220LHC-A001-1022 LED (no display) Cutter No — View product
DH220LHC-A001-1032 LED (no display) Cutter Yes — View product
DH220LHC-A001-1042 LED (no display) Tear-off Yes — View product
DH220LHC-A001-1102 LED (no display) Tear-off No Wi-Fi + Bluetooth View product
DH220LHC-A001-1112 LED (no display) Peeler No Wi-Fi + Bluetooth View product
DH220LHC-A001-1122 LED (no display) Cutter No Wi-Fi + Bluetooth View product
DH220LHC-A001-1132 LED (no display) Cutter Yes Wi-Fi + Bluetooth View product
DH220LHC-A001-1142 LED (no display) Tear-off Yes Wi-Fi + Bluetooth View product
DH220LHC-A001-1202 LED (no display) Tear-off No Bluetooth (MFi) View product
DH220LHC-A001-1212 (this version) LED (no display) Peeler No Bluetooth (MFi) Viewing
DH220LHC-A001-1222 LED (no display) Cutter No Bluetooth (MFi) View product
DH220LHC-A001-1232 LED (no display) Cutter Yes Bluetooth (MFi) View product
DH220LHC-A001-1242 LED (no display) Tear-off Yes Bluetooth (MFi) View product

Technical Specifications

Part Number DH220LHC-A001-1212
Model TSC DH220LHC (DH220L Series for Healthcare, 2-inch)
Printer Type 2-inch direct thermal desktop label printer for healthcare
Print Method Direct thermal
Resolution 203 dpi (8 dots/mm)
Print Speed Up to 203 mm/s (8 ips)
Max Print Width 54 mm (2.13")
Max Print Length 25,400 mm (1,000")
Media Width 10–60 mm (0.39"–2.36")
Media Thickness 0.06–0.19 mm (2.36–7.48 mil)
Roll Diameter 165 mm (6.5") OD
Core Size 25.4–38.1 mm (1"–1.5")
Media Types Continuous, die-cut, black mark, fanfold, notched (outside wound), tags and patient wristbands; label length 5 mm – 25,400 mm
Sensors Transmissive gap sensor, reflective black-mark sensor (position adjustable), head-open sensor
Interfaces USB 2.0, RS-232 serial, internal Ethernet 10/100 Mbps, USB host; microSD card slot
Wireless MFi Bluetooth (factory-installed, for iOS and Android)
Processor 32-bit RISC CPU
Memory 256 MB SDRAM, 512 MB Flash; microSD expansion up to 512 GB (FAT32/exFAT)
Real-Time Clock Standard (plus buzzer)
Printer Languages TSPL-EZD with automatic EPL, ZPL, ZPL II and DPL language switching
Fonts / Character Sets 8 alphanumeric bitmap fonts; Monotype true-type engine with CG Triumvirate Bold Condensed; ARIALUNI.TTF Unicode font (UTF-8); 0/90/180/270° rotation
Barcodes 1D: Code 39, Code 93, Code 128 (UCC, subsets A/B/C), Codabar, Interleaved 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN/UPC add-on, MSI, Plessey, Postnet, China Post, ITF-14, EAN-14, Code 11, Telepen, Planet, Code 49, Deutsche Post Identcode/Leitcode, LOGMARS; 2D: TLC39, Codablock F, PDF417, MicroPDF417, MaxiCode, DataMatrix, QR Code, Aztec, GS1 DataBar
Display No display – LED status and icon indicators; power, feed, pause and reprint buttons
Media Options Peel-off module (factory-fitted)
Options Guillotine cutter, peel-off module, linerless cutter kit, linerless tear-off kit, Wi-Fi + Bluetooth 5.0 combo module, HF RFID tear-off upgrade kit, external label roll mount, KP-200 Plus keyboard, 10 mm narrow media adaptor
Management & Security Internal embedded web page, virtual control panel, TSC Console, SOTI Connect (licence); HTTPS, SNMPv3, 802.1X, TCP/IP port 9100 filter; TPH Care printhead diagnostics
Enclosure Double-walled clamshell; disinfectant-ready, antibacterial white plastic with easy-to-clean surface and sealed buttons
Power Supply IEC 60601-1 certified universal switching power supply: 100–240 V AC, 2.0 A, 50–60 Hz input; 24 V DC, 2.5 A, 60 W output
Weight approx. 1.6 kg (3.6 lb)
Color White
Operating Temperature 0–40 °C, 25–85% RH non-condensing
Storage Temperature −40–60 °C, 10–90% RH non-condensing
Warranty Printer: 3 years (TSC EMEA); printhead 25 km or 12 months, platen 50 km or 12 months (whichever comes first)
In the Box TSC DH220LHC printer (203 dpi, LED indicators, no display, USB 2.0 + RS-232 + Ethernet + USB host, MFi Bluetooth, factory-fitted peel-off module), IEC 60601-1 medical-grade power supply (24 V DC, 60 W), power cord (EU Schuko plug), USB cable, quick start guide – labels NOT included

Need a different display, media option or wireless option? All DH220LHC versions are listed above. Compare other models in our Desktop Label Printers collection or contact our team for volume pricing.
